JBL BAR 1000 7.1.4-Channel Soundbar with Detachable Surround Speakers, MultiBeam™, Dolby Atmos®, and DTS:X®

1 x Main soundbar

2 x Detachable wireless surround speakers

1 x Wireless subwoofer

1 xRemote control with 2 x batteries

Power cords (up to 8pcs depending on region SKUs)

1 x HDMI cable

2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws

4 x Side caps

1 x Quick start guide

1 x Safety instruction and Warranty card

1 x Wall mount template

Model: BAR 1000 (soundbar unit), BAR 1000 SURROUND (detachable speaker) BAR 1000 SUB (subwoofer unit)

Sound system: 7.1.4 channel

Power supply: 100 - 240V AC, ~ 50/60Hz

Total speaker power output (Max @THD 1%): 880W

Soundbar output power (Max @THD 1%): 440W

Surround speaker output power (Max @THD 1%): 2x 70W

Subwoofer output power (Max @THD 1%): 300 W

Soundbar transducer: 5 x (46x90)mm racetrack drivers, 3x 0.75” (20mm) tweeters, 2 x 2.75” (70mm) up-firing full-range drivers

Surround speaker transducer: 0.75” (20mm) tweeters, 2.75” (70mm) up-firing full-range drivers

Subwoofer transducer: 10” (260mm)

Networked standby power: < 2.0W

Operating temperature: 0°C - 45°C

Lithium battery: 3.635V, 3283mAh

Detachable surround speaker playtime: up to 10 Hours (may vary according to content type and volume level)

Video

HDMI video input: 3

HDMI video output (with Enhanced Audio Return Channel, eARC): 1

HDMI HDCP version: 2.3

HDR pass-through: HDR10, Dolby Vision

Audio

Frequency response: 33Hz – 20kHz (-6dB)

Audio inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

USB

USB port: Type A

USB rating: 5V DC, 0.5A

Supported file format: MP3

MP3 codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate: 16 - 48 kHz

MP3 bitrate: 80 – 320 kbps

USB port: Type A

Wireless

Bluetooth version: 5.0

Bluetooth profile: A2DP 1.2, AVRCP 1.5

Bluetooth transmitter frequency range: 2400MHz - 2483.5MHz

Bluetooth transmitter power: <15dBm (EIRP)

Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)

2.4G Wi-Fi transmitter frequency range: 2412 - 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 channels)

2.4G Wi-Fi transmitter power: < 20dBm (EIRP)

5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725-5.825GHz

5G Wi-Fi transmitter power: 5.15 - 5.25GHz <23dBm, 5.25 - 5.35GHz & 5.47 - 5.725GHz <20dBm, 5.725 - 5.825GHz <14dBm (EIRP)

2.4G wireless frequency range: 2406 - 2474MHz

2.4G wireless power: <10dBm (EIRP)

Dimension

Main soundbar dimensions (W x H x D): 884 x 56 x 125 mm / 34.8” x 2.2” x 4.9”

Detachable surround speaker dimensions (each) (W x H x D): 155 x 56 x 125 mm / 6.1” x 2.2” x 4.9”

Subwoofer dimensions (W x H x D): 305 x 440.4 x 305 mm / 12” x 17.3” x 12”

Soundbar weight: 3.7 kg / 8.2 lbs

Detachable surround speaker weight (each): 0.7kg / 1.55 lbs

Subwoofer weight: 10 kg / 22 lbs

Packaging dimensions (W x H x D): 1000 x 375 x 475 mm/ 39.4” x 14.8” x 18.7”

Packaging Weight: 19.4 kg / 42.7 lbs
